ENGLISH
4
BEFORE YOU BIND
1. Check the green power neon is on. 2. Select the correct comb diameter
using the comb storage tray.
3. Insert the plastic comb into the
opening mechanism.
21 3
4. Pull comb-opening lever forward to
open the comb.
5. Test punch scrap sheets to check
edge guide setting.
54
STEPS TO BIND
1. Punch front and back covers
first.
2. Punch sheets in small
batches that do not overload
the machine or the user.
3. Load punched sheets directly
onto the opened comb. Starting
with the front of the document.
4. When all punched sheets are
loaded onto the comb, push the
comb lever backwards to close
the comb and remove the bound
document.
21 3 4
30
30
Back
Cover
30
Front
Cover
MAX 20
(80gsm)
