Ef
Ef
fects Select
fects Select
Select from 16 variations of 6 effect types. Delay
produces various echoes, Reverb creates the
acoustic ambience of different spaces or classic
Fender spring Reverb, Chorus and Flange modulate
the pitch and delay of a superimposed signal
double, Tremolo modulates volume, Vibratone
generates the doppler effect a rotating speaker.
7
SS
SS
pp
pp
ee
ee
cc
cc
ii
ii
ff
ff
ii
ii
cc
cc
aa
aa
tt
tt
ii
ii
oo
oo
nn
nn
ss
ss
TYPE: PR 575
PART NUMBER: 2267200040 (120V, 60Hz) US 2367201940 (110V, 60Hz) TW
2367203940 (240V, 50Hz) AUS 2367204940 (230V, 50Hz) UK
2367205940 (220V, 50Hz) ARG 2367206940 (230V, 50Hz) EUR
2367207940 (100V, 50Hz) JPN 2367209940 (220V, 60Hz) ROK
POWER REQUIREMENTS: 360W
POWER OUTPUT: 90W RMS into 4Ω @ 5%THD
INPUT IMPEDANCE INPUT 1: 2.2MΩ
INPUT 2: 136kΩ
FUSES: 4A 125V for 100V/110V/120V ver
1.25A 250V for 220V/230V/240V ver
FOOTSWITCH: 3-Button (P/N 064465),
Channel Select / Drive Select / Effects Bypass
SPEAKER COMPLEMENT: One 4Ω, 12” Celestion G12T-100 (P/N 054421)
DIMENSIONS HEIGHT: 16.5 in (42 cm)
WIDTH: 20.6 in (52.3 cm)
DEPTH: 9.0 in (30.5 cm)
WEIGHT: 33 lb (15 kg)
Product specifications are subject to change without notice.
EE
EE
ff
ff
ff
ff
ee
ee
cc
cc
tt
tt
ss
ss
SELECTION DESCRIPTION TIME/RATE
1 Digital (minimum repeat)
DELAY 2 Tape Echo (moderate repeat) Delay Time
3 Ducking (volume priority, more repeat)
1 Room Acoustics
REVERB 2 Hall Acoustics Decay Time
3 Fender
®
Spring Reverb
Combination
4 Reverb + Delay Delay Time
1 Light Sweep
2 Deep Sweep
3 Chorus + Delay Delay Time
4 Chorus + Reverb Chorus Rate
1 Light Sweep
2 Deep Sweep
1 Low Intensity
2 High Intensity
VIBRATONE 1 Rotary Speaker Revolution Rate
CHORUS
Combinations
FLANGE
TREMOLO
Chorus Rate
Flange Rate
Tremolo Rate
