BLUES JUNIOR
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 049306001 PCB ASSY BLUES JUNIOR ALL V (STUFFED)
1 028104000 BUTTON PUSH SWITCH BLACK (@ S1)
2 047093000 CABLE 6 CKT 3.2" CJ1,3
3 029533000 CABLE JMPR 22GA 4 CKT 3.2" CJ2,4,5
1 028577000 CABLE REVERB 30" (@ P1,2,3,4)
1 038689001 CAP AE AX .47µF 100V C23
3 009512001 CAP AE AX 22µF 25V 20% C3,4,21
3 024819000 CAP AE AX 22µF 500V C10,17,18
1 041589000 CAP AE AX 47µF 500V 20% C15
1 028474000 CAP AE RDL 100µF 25V 20% C14
2 028479000 CAP AE RDL 220µF 25V 20% C29,30
2 028489000 CAP AE RDL 470µF 50V 20% C27,28
1 039255001 CAP CA 10PF 100V LL C24
1 020909000 CAP CD 47PF 1000V 10% C33
1 069724000 CAP CD 100PF 1000V10% C&F C2
1 020917000 CAP CD 250PF 1000V 10% C25
1 020867000 CAP CD 330PF 1000V 10% C20
1 017620000 CAP CD 1500PF 1000V 10% C35
1 039265001 CAP CA 2200PF 100V LL C22
2 026202000 CAP PFF .0022µF 600V C1,16
1 033581000 CAP PFF RDL .0033µF 100V 10% C26
1 033588000 CAP PFF RDL .01µF 100V 10% C31
2 024823000 CAP MPF RDL .01µF 400V 10% C6,34
1 036234000 CAP PFF RDL .015µF 100V 10% C12
4 024833000 CAP MPF RDL .022µF 400V 10% C8,9,11,13
1 024839000 CAP MPF .033µF 400V C19
2 024853000 CAP MPF RDL .1µF 250V 10% C5,7
1 024855000 CAP MPF RDL .1µF 630V 10% C32
1 049402000 CONTROL 25K B SNAPIN R29
2 034719000 CONTROL 50KB SNAP IN R41,51
1 041913000 CONTROL SNAPIN 250K 10A R8
1 040985000 CONTROL SNAPIN 250K B R28
1 049401000 CONTROL 1M 10A R7
2 064089001 DIODE 1N4003 LL CR5,7
4 026730001 DIODE 1N4006 800V LL CR1,2,3,4
2 006260001 DIODE 1N4448 SIGNAL LL CR6,12
2 029690001 DIODE HV 3KV 200MA LL CR10,11
2 009165001 DIODE ZEN 1N4744A 15V 1W 5% CR8,9
16 025802000 FSTN TAB MALE .250X.032 PCB MT CP1-13,16-18
2 031041000 FSTN TAB ML RTANG PCB .25X.032 CP14,15
2 025996000 FUSE CLIP PCB .250 & 5MM FUSE XF1
1 048827 FUSE QA 1-1/4X1/4 250V 2A F1 (100V/120V ONLY)
1 020789 FUSE QA 20mmX5mm 250V 1 AMP F1 (230/240V EXPORT ONLY)
1 016795 IC DUAL OP AMP TLO72 U1
1 030771 JACK 1/4 PCB 2/CD SCC J2 (SPEAKER JACK)
1 027674 JACK 1/4 PCB 2/CD SCC INSL J3 (FOOTSWITCH JACK)
1 037036 JACK PHONE PCB MONO CA PREMIUM J1 (INPUT JACK)
26 020888001 JUMPER WIRE 22GA .5" W1-26
1 048332 LED RED PNL MT 7" LD1
1 049305 PCB FAB BLUES JUNIOR (RAW BOARD)
1 024947001
RES CF 1/4W 5% 47Ω LL
R45
1 024964001
RES CF 1/4W 5% 280Ω LL
R15
5 024969001 RES CF 1/4W 5% 1.5K LL R4,11,20,23,38
1 029005001 RES CF 1/4W 5% 2K LL R49
