Fender Frontman 15R User Manual

FRONTMAN 15/15R
SPECIFICATIONS
Product Release No.: PR 330/343 (This is not a model number)
Part Number: Frontman 15 Frontman 15R
120V Version: 22-1500 22-1501
240V Aust : 22-1530 22-1531
230V UK : 22-1540 22-1541
230V : 22-1560 22-1561
100V : 22-1570 22-1571
230V Nord : 22-1580 22-1581
Input impedance: >1M ohm
Nominal level: 100mV
Power output: 15 Watts RMS into 8 ohms @ 5% THD
Power Requirements: 120V Version: 120 VAC 60 Hz, .28A Max
230V: 230 VAC 50 Hz, .14A Max
Speaker Complement: One 8 Ω Special Design 8" Speaker (P/N 025421)
Dimensions: Height:12-3/8" (31.4 cm)
Width: 13-1/4" (33.7 cm)
Depth: 7-1/8" (18.1 cm)
Weight: 15 lbs. (6.8 kg)
FRONTMAN 15/15R
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
The parts and quantities are listed for the "Frontman 15R" only. Parts used in the Reverb circuit are simply not stuffed in the
"frontman15"
1 050785 PCB ASSY FRONTMAN REVERB
1 048451 BUTTON PUSH OFF WHITE (@ S1)
2 038689 CAP AE AX .47µF 100V 20% C12,13
2 026517 CAP AE AX 2.2µF 50V C4,24
1 038691 CAP AE AX 4.7µF 50V 20% C23
2 025960 CAP AE AX 22µF 16V C7,34
1 038693 CAP AE AX 47µF 16V 20% C26
2 028471 CAP AE RDL 47µF 50V 20% C31,32
2 033607 CAP AE RDL 2200µF 35V 20% C29,30
1 039255 CAP CA 10PF 100V 5% C22
2 038698 CAP CA 47PF 100V 5% C3,36
1 039256 CAP CA 68PF 100V 5% C21
1 038699 CAP CA 100PF 100V 5% C25
1 038701 CAP CA 470PF 50V 5% C11
1 038874 CAP CA 560PF 50V 5% C14
2 039268 CAP CA 4700PF 50V 5% C1,2
2 038703 CAP CA .1µF 50V 10% C6,33
1 027278 CAP MPF .1µF 63V 10% C27
1 027286 CAP MPF .47µF 63V C28
2 033580 CAP PFF RDL .0022µF 100V 10% C5,35
1 033581 CAP PFF RDL .0033µF 100V 10% C18
1 033583 CAP PFF RDL .0047µF 100V 10% C19
1 036234 CAP PFF RDL .015µF 100V 10% C38
1 033590 CAP PFF RDL .022µF 100V 10% C16
2 033591 CAP PFF RDL .033µF 100V 10% C9,10
4 033592 CAP PFF RDL .047µF 100V 10% C8,15,17,20
1 033596 CAP PFF RDL .068µF 100V 10% C37
2 034719 CONTROL 50KB SNAP IN R29,58
1 037323 CONTROL 50K 15A SNAP IN R13
3 037324 CONTROL 100K 30C SNAP IN R20,24,28
1 040552 CONTROL 250K 30C R30
4 006260 DIODE 1N4448 SIGNAL BENT CR1-CR4
6 064089 DIODE 1N4003 200PRV,1AMP CR5-10
2 009165 DIODE ZEN 1N4744A 15V 1W 5% CR11-CR12
2 025996 FUSE CLIP PCB .250 & 5MM FUSE XF1
1 068411 FUSE QA 1-1/4X1/4 250V 0.5AMP F1 (100V/120V ONLY)
1 020781 FUSE QA 20mmX5mm 250V 0.25AMP F1 (230V/240V ONLY)
2 027408 HDR .1 CTR 2 CKT SQ PIN P10,P11
2

Fender Frontman 15R Specifications

General

Power Output	15 watts
Channels	2 (Normal and Drive)
Reverb	Yes
Headphone Jack	Yes
Weight	15 lbs (6.8 kg)
Type	Solid State
Effects	Reverb
Speaker	8" Fender Special Design Speaker
Inputs	1 x 1/4" Instrument
Controls	Volume, Treble, Bass, Reverb
