Fender Frontman 15R User Manual

FRONTMAN 15/15R
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 037030 HEATSINK FENDER X-15
4 016795 IC DUAL OP AMP TL072 U1,2,3,5
1 029912 IC PC1188H 20W U4
1 041988 INSULATOR MICA 10 PIN SIP (@ U4)
1 031570 JACK PHONE PCB STEREO PREMIUM J3
2 037036 JACK PHONE PCB MONO CA PREMIUM J1,2
12 020888 JUMPER WIRE 22GA .5X.175
1 028039 LED RED 5X5MM SLB-55VR3 LD3
2 9902202281 LED RED LONG LEAD LUMEX CS02 LD1,LD2
1 041409 PCB FAB BULLET AMPS (BLANK)
1 024942 RES CF 1/4W 5% 22_ R54
2 024964 RES CF 1/4W 5% 820_ R38,42
1 024965 RES CF 1/4W 5% 1K R7
1 024969 RES CF 1/4W 5% 1.5K R50
1 024971 RES CF 1/4W 5% 2.2K R12
3 024973 RES CF 1/4W 5% 3.3K R19,21,57
1 028034 RES CF 1/4W 5% 5.1K R5
1 024979 RES CF 1/4W 5% 6.8K R3
1 024980 RES CF 1/4W 5% 8.2K R18
1 024981 RES CF 1/4W 5% 10K R55
3 024985 RES CF 1/4W 5% 15K R1,6,34
6 024987 RES CF 1/4W 5% 22K R8,16,17,32,52,53
5 024993 RES CF 1/4W 5% 47K R11,26,27,31,33
1 026507 RES CF 1/4W 5% 62K R43
3 024997 RES CF 1/4W 5% 100K R37,47,51
1 024999 RES CF 1/4W 5% 150K R39
2 025058 RES CF 1/4W 5% 180K R9,36
6 025059 RES CF 1/4W 5% 220K R10,14,15,23,25,56
2 025065 RES CF 1/4W 5% 470K R22,35
2 028018 RES CF 1/4W 5% 510K R2,4
1 025073 RES CF 1/4W 5% 1.5M R59
1 030737 RES CF 1/2W 5% 5.6_ R40
2 028045 RES FILM 1W 5% 220_ R48,49
2 028740 RES FILM 1W 5% 470_ R45,46
1 039128 RES FILM 1W 5% 120_ R44
1 032958 RES WW BT 5W 10% .33_ R41
2 027638 SCRW TF 4-40X3/8 HWHS ZI (U4 TO HEATSINK MOUNT)
2 032908 SCRW TF 6-32X/38 PHP ZI (HEATSINK TO PCB MOUNT)
1 9904701440 SPACER LED .7X.125 BLUE (@ LD3)
1 028091 SWITCH PUSH SLFLK SHORT STROKE S1
FRONTMAN 15/15R
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050786 CHS ASSY FRONTMAN REVRB AMP 120V
1 050710 CHS ASSY FRONTMAN 120V
1 051330 CABLE ASSY 120V 6 FT (100V/120V ONLY)
1 050725 CABLE ASSY PWR 230V .187 TAB (230V ONLY)
7 026402 KNOB POINTER BLACK
1 050766 PANEL FRONT FRONTMAN REVERB
1 050704 PANEL FRONT FRONTMAN
5 028684 SCRW SMB 6X3/8 PH PHS BLX (PCB/XFMR MOUNT)
1 025935 SWITCH POWER DPST (120V DOMESTIC ONLY)
1 039287 SWITCH POWER DPST .187 TAB GLOBAL (230V/240V EXPORT ONLY)
5 026459 WSHR FLAT 6X3/8 ZI (PCB/XFMR MOUNT)
3 031647 NUT HEX 12mm x 1 mm NI
1 038900 SCRW TF 6-32 x 1/4 PHP ZI
1 050706 CHASSIS FRONTMAN
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050709 CAB ASSY FRONTMAN
1 022491 CLAMP CABLE NYL SCRW MNT 5/16 (@ POWER CABLE)
2 050348 FOAM STRIP 1/8X1X7 DBL STICK (REVERB PAN TO SLEEVE) +
(SLEEVE TO CHASSIS)
1 050754 GRILLE FRONTMAN
1.96 051204 FOAM TAPE 1/4" 1/16 3M4516 @ GRILLE TOP & BOTTOM
1 050767 LABEL REAR FRONTMAN REVERB (@ CABINET BACK)
1 050705 LABEL REAR FRONTMAN (@ CABINET BACK)
1 029906 NAMEPLATE FENDER GENERIC SMALL
1 041397 REVERB SPRING 1BB2E4A (REVERB PAN)
16 026571 SCRW CORNER MOUNTING
2 022277 SCRW M 10-32X1-1/2 OHP NI (HANDLE MOUNT)
1 029828 SCRW PB 8X3/4 PHP ZI (CABLE CLAMP MOUNT)
4 9904101110 SCRW PB 8X5/8 PHP (FOOT MOUNT)
2 018113 SCRW SMA 4X1/2 OHP BLX (LOGO MOUNT)
4 016627 SCRW SMAB 8X3/4 OHP BLX (GRILLE BAFFLE MOUNT)
4 029677 SCRW SMA 6X1 THP BLX (BACKBOARD MOUNT)
2 022152 SCRW SMA 3X1/2 OHP BLX
1 025954 SLEEVE-REVERB PAN CHAMP 12 (CARDBOARD OVR REVRB PAN)
4 029527 WSHR FNSH 8-5/8 FLNGD BLX WX (GRILLE BAFFLE MOUNT)
3

Fender Frontman 15R Specifications

General

Power Output	15 watts
Channels	2 (Normal and Drive)
Reverb	Yes
Headphone Jack	Yes
Weight	15 lbs (6.8 kg)
Type	Solid State
Effects	Reverb
Speaker	8" Fender Special Design Speaker
Inputs	1 x 1/4" Instrument
Controls	Volume, Treble, Bass, Reverb
