HOT ROD DEVILLE
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 026368001 RES CF 1/2W 5% 100OHM R80,81
1 025115001 RES CF 1/2W 5% 82K R57
5 025116001 RES CF 1/2W 5% 100K R4,11,16,22,58
4 025117001 RES CF 1/2W 5% 220K R70,71,72,73
1 033095001 RES MOX FP 1W 5% 1 OHM R66
2 036468001 RES MOX FP 1W 470OHM R62,62
1 036469001 RES MOX FP 1W 5% 4.7K R74
1 036621001 RES CF 1W 5% 6.8K R56
1 036470001 RES MOX FP 1W 5% 10K R75
1 041277 RES CF 2W 5% 820 OHM R97
2 028037 RES WW BT 5W 10% 330 OHM R78,79
4 014999 SCRW M 6-32X1/4 PHP ZI @XV4,5
13 039367 SCRW M 6-32X3/8 PHPS SS ITLW PCB MOUNT
1 036178 SPACER LED .5X.1 BRN @LD1
13 016440 STNDOFF RND AL 6-32X1X1/4 PCB MOUNT
3 028091 SWITCH PUSH SLFLK SHORT STROKE S1.2.3
1 028503 THERMISTOR 10 OHM 5A C60-11 TH1
3 029167 TUBE SOCKET 9 PIN PCB MOUNT XV1.2.3
2 029343 TUBE SOCKET 8 PIN PCB MOUNT XV4,5
2 014689 XSTR N-CH JFET J111 TO-92 Q4
1 016739 XSTR NPN 2N4401 TO-92 Q4
1 016742 XSTR PNP 2N4403 TO-92 Q3
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 026038 BUSHING SR .625X.062X37/64 BLK @ PWR CABLE 100V,120V, AUSTRALIA
1 010401 BUSHING SR .625X.125X37/64 WHT @PWR CABLE 230V, UNITED KINGDOM
1 026116 BUSHING SR .500X.063X7/16 BLK
1 026541 CABLE ASSY PWR W/.250 TAB 120V
1 048463 CABLE ASSY PWR .250 TAB 100V (POWER CABLE 100V ONLY)
1 033331 CABLE ASSY PWR 220/240V (POWER CABLE 230V ONLY)
1 038602 CABLE ASSY PWR AUST. .250 TAB (PWR CABLE AUSTRALIA 240V)
1 040993 CABLE ASSY PWR 5A U.K. .250 TAB (P CABLE UNTIED KINGDOM 240V)
1 022707 CHOKE FILTER L1
1 032219 COLLAR-PILOT LIGHT
1 077982 FUSE QA 1-1/4X1/4 250V 3A F1 100V/120V ONLY
1 020793 FUSE QA 20mmX5mm 250V 1.6A F1 220V/230V/240V ONLY
1 036702 FUSE HOLDER 3AG FINGER GRIP 100/120V ONLY
1 036703 FUSE HOLDER 5MM FINGER GRIP 230V, AUSTRALIA, UK
1 021741 HOLDER DIAL LITE ASSEMBLY PILOT
1 021550 JACK PHONE TIP SHUNT 12A J7 SPEAKER OUT JACK
1 041701 JACK PHONE TRANSFER 13A J6 EXT. SPEAKER JACK
1 025718 JEWEL PILOT LITE RED #20
8 036620 KNOB “CHICKEN HEAD
1 031625 NUT HOLDER PILOT LITE 1/16-27
8 022004 NUT KEPS #8-32 ZINC
2 016352 NUT HEX 3/8-32X3/32 TK NI
1 050403 PANEL TOP CHRM H/R DVL/DLX
1 021842 PILOT LIGHT #T47 BULB
21 031184 SCRW M 8-32X1/2 PHP ZI
4 038900 SCRW TF 6-32X1/4 PHP ZI
4 016473 SCRW M 8-32X1/2 PHP ZI
6 016440 STNDOFF RND AL 6-32X1X1/4
1 036570 SWITCH TOGGLE DPST W/NUTS S4 POWER SWITCH
1 037039 SWITCH TOGGLE SPST W/NUTS S5 STANDBY SWITCH
3 013341 TUBE 7025/12AX7WAWA RUSSIAN MADE V1,2,3
2 039214 TUBE 5881/6L6WGC V4,5
2 020424 TUBE RING UNIVERSAL (277H-2) @V4,5
7 9904300920 WASHER FLAT .482X.709 NI
2 9904300100 WASHER LCK INTL 3/8X.709 NI
1 041752 XFMR PWR CNCRT/SUPR/HR/DVL 120 T2 120V ONLY
1 041753 XFMR PWR ’93 CONCERT/SUPER EXP T2 100V/115V/230V
1 041754 XFMR OUTPUT ’93 CONCERT/SUPR T1
