KXR 200
SPECIFICATIONS
Product Release No.: PR 286 (This is not a model number)
Power output: 200 Watts RMS
Distortion at 200 watts: Less than .1% @ 1kHz, below compression
Less than 1% @ 1kHz, maximum compression
Rated Load Impedance: 4 Ω
Input impedance: 22K Ohms
Sensitivity: 1.03V RMS
DELTACOMP Range: 20dB
PREAMP SECTION:
Input Impedance: XLR – 1.82K Ω
Phone – 18.2k Ω
Senitivity for 200 watts: XLR – 2.9mV RMS
Channel and master Phone – 29mV RMS
Volume at maximum, all
Tone controls at “0”
Equalizer: For 3-band-EQ sections:
+/- 12dB at 130,540 and 4200 Hz
Sensitivity for channel 500mV RMS (-6dBV)
Inserts, Master volume
At maximum setting
Sensitivity for Master 130mV RMS (-18dBV)
Volume and FX return
Control at maximum
Dimensions:
Height:29 3/4" (75.6 cm) (w/o casters)
Width: 21 11/16" (55.1 cm)
Depth: 12" (30.5 cm)
Weight: 88 lbs. (40.0 kg)
Product specifications are subject to change without notice
