PARTS LIST
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048526 CHS ASSY PRNCETON 112PLUS 120V
9 033206 BUSHING KNOB SPACER
1 021709 BUSHING SR .437x.062x13/32 BLK (@ SPEAKER CABLE)
1 026116 BUSHING SR .500x.063x7/16 BLK (@ REVERB CABLE)
1 026038 BUSHING SR .625x.062x37/64 BLK (@ PWR CABLE 100/120V ONLY)
1 010401 BUSHING SR .625X.125X37/64 WHT 230V (@ POWER CABLE 230V)
1 026527 CABLE ASSY POWER W/.187 TABS (POWER CABLE 100V/120V ONLY)
1 026528 CABLE ASSY POWER 230V W/.187 TABS (PWR CABLE 230V EXPORT ONLY)
1 036479 CABLE ASSY POWER AUST.W/.187 TABS (240V AUSTRALIA ONLY)
1 040542 CHS PRINCETON 112 (RAW CHASSIS)
1 028560 END BELL XFMR 85w (@ POWER TRANSFORMER)
1 028499 HEATSINK BAR (COUPLER TO CHASSIS)
9 026403 KNOB POINTER BLACK 180 DEG
4 028591 NUT ACORN 8-32 (TRANSFORMER MOUNT)
1 048844 PANEL FRONT PRINCETON 112 PLUS
1 048525 PANEL REAR PRINCETON 112 PLUS
4 028937 SCRW TF 6-32x5/8 PHP ZI ROLOK (PCB TO CHASSIS MOUNT)
1 038900 SCRW TF 6-32X1/4 PHP ZI (@ GROUND LUG)
3 028500 SCRW TF 8-32x3/4 HWH SLTD Z1 (CHASSIS TO HEATSINK MOUNT)
4 025936 STAND OFF PCB PUSH ON NY 3/8L (PCB TO CHASSIS MOUNT)
1 025935 SWITCH POWER DPST (120V DOMESTIC ONLY)
1 039287
*
SWITCH POWER DPST .187 TAB GLOBAL (EXPORT ONLY)
4 030007 WSHR LCK INTL 8x.330x.02 ZI (TRANSFORMER MOUNT)
1 027668 XFMR POWER 120V 85W (120V DOMESTIC ONLY)
1 039357 XFMR POWER EXPORT DELUXE 112 (100V/115V/230V)
FOOTSWITCH ASSEMBLY
(OPTIONAL)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028122 FOOTSWITCH 2 BTN REVERB F/LOGO (COMPLETE FOOTSWITCH)
2 006260 DIODE 1N4448/1N914B SIGNAL CR1,2
1 037036 JACK PHONE PCB MONO CA PREMIUM J1
2 028039 LED RED 5X5MM SLB-55VR3 LD1,2
2 028714 SWITCH PUSH SPDT S1,2
PARTS LIST
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040547 CAB ASSY PRINCETON 112 (COMPLETE CABINET)
1 022491 CLAMP CABLE NYL SCRW MNT 5/16 (@ REVERB CABLE)
4 026566 CORNER 2 HOLE w/TAB NI (TOP REAR, BOTTOM FRONT)
2 026568 CORNER 3 HOLE NI (BOTTOM REAR)
4 029821 EYELET RFLNGD .215 OD x.315 L (REVERB PAN MOUNT)
4 019276 GLIDE CAB 1.24x.335 NI (STEEL ONLY)
4 019275 GLIDE CUSHION INSERT (RUBBER ONLY)
1 040548 GRILLE BAFFLE ASSY PRNCTON 112 (COMPLETE GRILLE)
1 027846 HANDLE 9.25 (RUBBER ONLY, NO INSERT)
2 019279 HANDLE CAP 2-3/16 NI (HANDLE MOUNT)
1 032524 INSERT HANDLE (SPRING STEEL)
1 011298 NAMEPLATE FENDER SMALL (LOGO
4 021972 NUT T 10-32x3/4 STR 3 PRNG BLX (HANDLE MOUNT)
1 028055 REVERB UNIT 800 ohm 8EB2C1B DN (PAN)
10 026571 SCRW CORNER MOUNTING
4 022244 SCRW M 10-32x1-1/8 OHP NI (HANDLE MOUNT)
4 026625 SCRW WOOD 8x1 FH (GLIDE MOUNT)
4 026577 SCRW M 10-32x1 PHP BLX (SPEAKER MOUNT)
6 036199 SCRW M 8-32x1-3/16 OHP BLX WX (CHASSIS MOUNT)
5 029828 SCRW PB 8x3/4 PHP ZI (REVERB PAN/CABLE CLAMP MNT)
2 018113 SCRW SMA 4x1/2 OHP BLX (LOGO MOUNT)
2 011678 SCRW SMA 8x1-1/2 OHP BLX (GRILLE MOUNT)
1 025923 SPEAKER 12" 8ohm 75 WATT
8 029527 WSHR FNSH 8-5/8 FLNGD BLX WX (CHASSIS/GRILLE MOUNT)
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048524 MANUAL OWNERS PRINCETON 112
1 040536 SCHEM REDUCED W/SRV PRINCETON 112
