Bottom Panel Functions
Bottom Panel Functions
Specifications
Specifications
F. ELECTRIC LINE CORD - Make sure
the amplifier’s electrical supply rating
matches that of the outlet at your
location. Connect the power AC line
cord to a grounded receptacle only.
G.SPEAKER CONNECTOR - This jack
provides a connection for the 8-ohm
internal speaker OR any 8–ohm
external speaker cabinet.
TYPE: PR 257
PART NUMBERS: 120V, 60Hz US 021-3103-000
100V, 50/60Hz JPN 021-3173-000
230V, 50Hz EUR 021-3163-000
230V, 50Hz UK 021-3143-000
240V, 50Hz AUST 021-3133-000
POWER OUTPUT: 15W RMS minimum into 8-ohms
INPUT IMPEDANCE: >1MΩ
POWER REQUIREMENTS: 70W
SPEAKER COMPLEMENT: One 8-ohm, 10” Fender Special Design speaker (P/N-0048832000)
DIMENSIONS: HEIGHT: 14 in. (36.8 cm)
WIDTH: 15 in. (38.1 cm)
DEPTH: 8-3/4 in. (22.2 cm)
WEIGHT: 20 lbs. (14 kg)
Product specifications are subject to change without notice.
THIS EQUIPMENT CONFORMS TO
THE FOLLOWING DIRECTIVES :
EMC 89/336/EEC AND LV 73/23/EEC
