SPARE PARTS LIST FOR HB-10
REF NR DESCRIPTION FERM NR
2 685 MM EXTENSION BAR 104100
3 456 MM EXTENSION BAR 104101
4 250 MM EXTENSION BAR 104102
5 127 MM EXTENSION BAR 104103
6 SERRATED CAP 104104
7 SPREADING WEDGE, 1/2 TON 104058
8 BIG RUBBER HEAD 104105
9 BASE PLATE 104108
10 RAM TOE 104109
11 PLUNGER TOE 104110
12 CLEFT CAP 104111
13 “V” BASE 104112
14 HOLE CON NECTOR 104113
15 10 TON PUMP UNIT 104106
16 RAM UNIT 104107
17 HYDRAULIC HOSE 104067
- HOSE/UNIT CONNECTION BOLT 104065
- NUT FOR CONNECTION BOLT 104066
- REPAIR KIT 104114
EXPLODED VIEW HB-10
A
B
C
D
E
