96
Spare parts list
No. Description Position
503420 Left screw M5*25 1
410740 Keyless chuck plastic 13 mm 2
503422 Spindle with ball 3, 4
503423 Impact spring 5
503424 Bearing 6201 RS 6
503425 Big gear 8
503426 Needle bearing HK071208 9
503427 Impact block 10
503428 Impact selector set 11, 12
503429 Bearing 608 13
503430 Carbon brush holder set (2pc) 14, 16
503431 Carbon brush set (2pc) 15
503432 Rotor with fan 17
503433 Bearing 607 18
503434 Stator 19
503435 Switch 21
503436 Side handle with depth limiter 34
