6
EN
Mounting
• Place the chuck key (10) into one of the holes
in the chuck (6).
• Open the chuck (6) by turning the chuck key
(10) counterclockwise.
• Insert the drill bit (12) into the chuck (6).
• Close the chuck (6) by turning the chuck key
(10) clockwise.
• Remove the chuck key (10) from the chuck (6).
Removing
• Place the chuck key (10) into one of the holes
in the chuck (6).
• Open the chuck (6) by turning the chuck key
(10) counterclockwise.
• Remove the drill bit (12) from the chuck (6).
• Close the chuck (6) by turning the chuck key
(10) clockwise.
• Remove the chuck key (10) from the chuck (6).
Mounting and removing the auxiliary grip (fig.C)
Mounting
• Loosen the auxiliary grip (8).
• Slide the auxiliary grip (8) over the chuck (6).
• Turn the auxiliary grip (8) to the required
position.
• Tighten the auxiliary grip (8).
Removing
• Loosen the auxiliary grip (8).
• Remove the auxiliary grip (8) from the chuck (6).
• Tighten the auxiliary grip (8).
Mounting and removing the depth stop (fig. D)
The depth stop is used to set the maximum
drilling depth.
USE
Switching on and off (fig. A)
• To switch on the machine, press the on/off
switch (1). The further the on/off switch (1) is
pressed, the higher the speed of the machine.
• To switch the machine to continuous mode,
keep the on/off switch (1) pressed and
simultaneously press the lock-on button (2).
• To switch off continuous mode, press the on/
off switch (1) again.
Forward/reverse switch (fig. A)
Do not change the direction of rotation
during use.
• For clockwise rotation, slide the forward/
reverse switch (4) to the left.
• For counterclockwise rotation, slide the
forward/reverse switch (4) to the right.
Setting the operating mode (fig. E)
Do not change the operating mode
during use.
• Set the switch (5) to position ”A” for drilling.
• Set the switch (5) to position ”B” for hammer
drilling.
CLEANING AND MAINTENANCE
Before cleaning and maintenance, always
switch off the machine and remove the
mains plug from the mains.
• Regularly clean the housing with a soft cloth.
• Keep the ventilation slots free from dust and
dirt. If necessary, use a soft, moist cloth to
remove dust and dirt from the ventilation slots.
• Regularly clean the chuck and the drill bit to
avoid inaccuracies during use.
WARRANTY
Consult the enclosed warranty terms.
ENVIRONMENT
Disposal
The product, the accessories, and the
packaging must be sorted for
environmentally friendly recycling.
Only for EC countries
Do not dispose of power tools into domestic
waste. According to the European Guideline
2012/19/EU for Waste Electrical and Electronic
Equipment and its implementation into national
right, power tools that are no longer usable must
