Spare parts list
No. Description Position
503420 Left screw M5*25 1
503421 Keyed chuck 13mm 2
503438 Spindle with ball 3.9
503423 Impact spring 4
503424 Bearing 6201 RS 5
503425 Big gear 7
503426 Needle bearing HK071208 8
503439 Impact block 10
503440 Impact selector set 11..13
503429 Bearing 608 14
503441 Rotor with fan 15
503433 Bearing 607 16
503442 Bearing sleeve 17
503443 Stator 18
503444 Carbon brush set (2pc) 22
503445 Carbon brush holder set (2pc) 23.24
503446 Switch 28
503436 Side handle with depth limiter 37
503437 Chuck key
