27
03
Regular Maintenance
Figure 29. Rear Suspension Lubrication
(Both upper & lower a-arms)
RE-PACK
RE-PACK
BEARINGS
BEARINGS
ANUALLY
ANUALLY
RE-PACK
BEARINGS
ANUALLY
Figure 28. Front Caster & Wheel
Figure 27. Gearbox Drive Idler Pivot
Figure 26. Control Handle Pivots & Seat Pivots
