Ferris 5901692 - Lubricate the Front Casters

Not for
Reproduction
29
The operator platform and suspension pivot bearings (A,
Figure 34) are greased at the factory and do not require
maintenance.
Oil:
• Deck lift pivots.
• Discharge chute hinge.
• Ground speed control and parking brake lever pivots.
• Motion control shafts and linkages.
• Parking brake shafts and linkages.
Generally, all moving metal parts should be oiled where
contact is made with other parts. Keep oil and grease off belts
and pulleys. Remember to wipe fitting and surfaces clean
both before and after lubrication.
31
32
33
34
Lubricate the Front Casters
Interval:Annually
1. Remove the 1/4-28 bolt (A, Figure35) screwed into the
caster and install a 1/4-28 grease fitting.
