Never use an extension on the operation handle, but only use the grip on the handle.
When pulling the load, inspect the cable layout, which must be properly wrapped on the drum
with a spacing equal to the diameter of the cable (Figure 7).
Figure 7 – Arrangement of the cable.
5.2 Releasing the load
Before releasing the load, by unhooking the safety tab, hold the handle firmly!
1. Hold the operation handle of the winch with one hand in
a safe and secure manner;
2. Unhook the safety tab of the winch, with the other hand,
pushing it downwards as shown in Figure 8.
3. Rotate the handle anti-clockwise to unwind the cable from
the drum, releasing the load.
Figure 8 – Unhooking
