Fervi 0070/C - 2.1 Plate; 2.2 Technical specifications

MACHINES AND
ACCESSORIES
Page 6 out of 12
2.1 Plate
The following information plate is attached to the device
Figure 3 –Plate
2.2 Technical specifications
HAND GEARED WINCH WITH CABLE – Art. 0070/C
Maximum pulling capacity (kg)
500
Groove width (mm)
50
Outer coil diameter (mm)
133
Minimum coil diameter (mm)
40
Base dimensions (mm)
136 x 90
Cable diameter (mm)
4,5
Cable length (m)
10
