2 Symbols
Warning of general danger
Warning of electric shock
Read the operating instructions and
safety instructions.
Do not dispose of it with domestic
waste.
Pull out the mains plug
Wear a dust mask.
Do not climb on the unit
UKCA marking: The United Kingdom
Conformity Assessed symbol is a
marking for products being placed on
the market in the United Kingdom. It is
a manufacturers indication that the
product is in conformance with the rel
evant regulations in the UK.
3 Parts of the machine
[1-1]
Electrical outlet module
[1-2]
Cable and accessory holder
[1-3]
Suction hose mount
[1-4]
Handle
[1-5]
Lock
[1-6]
Filter drawer
[1-7]
Locking clip
[1-8]
Exhaust opening
[1-9]
Dirt trap
[1-10]
On/off switch
[1-11]
MAN button
[1-12]
Suction power adjustment
The specified illustrations appear at the begin
ning of the Operating Instructions.
4 Technical data
Mobile dust extractors
Power consumption 350–1200 W
Max. electrical outlet module connected load EU
CH, DK
GB
2200 W
1150 W
1610 W
Max. suction capacity (air), extractor/turbine 130 m³/h / 222 m³/h
Max. vacuum, turbine 24,000 Pa
Filter surface area 3508 cm²
Suction hose D 27/32 mm x 3.5 m
Mains power cable length 5.5 m
Sound pressure level as per EN 60335-2-69/uncertainty K 70 dB(A)
Hand-arm vibration value as per EN 60335-2-69/uncertainty K < 2.5 m/s² / 1.5 m/s²
Type of protection IP X4
Container capacity 15 l
Dimensions L x W x H 470 x 320 x 430 mm
Weight 11.2 kg
English
14
