Suitable for separation of dust
with an exposure limit value
greater than 0,1 mg/m
3
Do not dispose of it with domestic
waste.
Climbing prohibited
3 Parts of the machine
[1-2]
Appliance socket
[1-3]
SysDoc
[1-4]
Handle
[1-7]
Hose holder
[1-8]
T-Loc lock for Systainers
[1-9]
Dirt trap
[1-10]
Locking clip
[1-11]
On/off switch
[1-12] +
[1-13]
Brake
[1-14]
Exhaust opening
[1-15]
Filter drawer
[1-16]
Dedusting
[1-17]
MAN button
[1-18]
Manual suction hose adjust
ment (standby mode) or suction
power adjustment (extraction
mode)
[1-19]
Connection display
[1-20]
Connection button
The specified figures appear at the beginning of
the operating manual.
4 Technical data
Mobile dust extractors
Power consumption 350–1200 W
Max. electrical outlet module connected load EU, KR, CN
CH, DK
GB 230 V/110 V
2200 W
1150 W
1610 W/770 W
Max. suction capacity (air), extractor/turbine 130 m³/h / 222 m³/h
Max. vacuum, turbine 24,000 Pa
Filter surface area 3369 cm²
Suction hose D 27/32 mm x 3.5 m-AS
Mains power cable length 7.5 m
Sound pressure level as per EN 60335-2-69/uncertainty K 70 dB(A)/3 dB
Hand-arm vibration value as per EN 60335-6-69/uncertainty K < 2.5 m/s² / 1.5 m/s²
Degree of protection IP X4
Container capacity CTM MIDI I 15 l
Dimensions L x W x H CTM MIDI I 470 × 320 × 495 mm
Weight CTM MIDI I 11.3 kg
5 Intended use
Mobile dust extractor suitable for
– extracting dust up to 0.1 mg/m³ according
to dust class M including wood and paint
dust,
– extracting water,
– for increased loads during commercial use,
according to IEC/EN 60335-2-69.
The user is liable for improper or non-in
tended use.
English
15
