Q U A D R I L L
11
GB
Original operating manual
1Technical data
Noise/vibration information
Levels determined in accordance with EN 60745 are
typically:
Vibration emission value a
h
(vector sum for three
directions) and uncertainty K measured in accor-
dance with EN 60745:
The specified emissions values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary esti-
mates regarding vibration and noise loads during
operation.
– They represent the primary applications of the
power tool.
Drill / Impact drill DR 18/4 E PD 20/4 E
Power 705 W
No-load speed 1st gear 0 - 400
rpm
0 - 400
rpm
2nd gear 0 - 850
rpm
0 - 850
rpm
3rd gear 0 - 1900
rpm
0 - 1900
rpm
4th gear 0 - 4000
rpm
0 - 4000
rpm
Impact count 1st gear - 0 - 8200
rpm
2nd gear - 0 - 17000
rpm
3rd gear - 0 - 38000
rpm
4th gear - 0 - 79000
rpm
Chuck clamping range 1,5 - 13 mm
Max. drilling diameter Wood 50 mm
Metal 18 mm
Concrete 20 mm
Fastening into wood 10 mm
Tool holder in drill spindle 1/4 ’’
Collar 43 mm
Weight 1,7 kg
Safety class /II
DR 18/4 E PD 20/4 E
Sound pressure level L
PA
86 dB(A) 105 dB(A)
Noise level L
WA
97 dB(A) 116 dB(A)
Uncertainty K 3 dB 3 dB
DR 18/4 E PD 20/4 E
Drilling into metal a
h
= 5.0 m/s
2
a
h
= 5.0 m/s
2
Impact drilling into concrete - a
h
= 15.0 m/s
2
Fastening a
h
< 2.5 m/s
2
a
h
< 2.5 m/s
2
Uncertainty K = 1,5 m/s
2
K = 1,5 m/s
2
CAUTION
When working with noise
Damage to hearing
Always use ear protection.
