14
TXS
GB
Side of the belt clip
[2-1]
can be replaced when
battery pack is removed.
6.2 Charging the battery pack [3]
The LED
[3-1]
on the charger indicates the respec-
tive operating status of the charger.
7 Settings
7.1 Changing direction of rotation [1-5]
• Switch to the left = clockwise rotation
• Switch to the right = counterclockwise rotation
7.2 Changing gear [1-4]
• Gear switch forwards (digit 1 visible) = 1st gear
• Gear switch to rear (digit 2 visible) = 2nd gear
7.3 Adjust torque [1-2]
The marking
[1-3]
shows the selected position.
Drilling
Marking shows the drill symbol
[1-1]
= Maximum
torque.
Fastening
Torque corresponding to setting:
Position 1 = low torque
Position 12 = high torque
8 Tool holder, attachments
The order numbers of the accessories and tools can
be found in the Festool catalogue or on the Internet
under "www.festool.com".
8.1 CENTROTEC tool chuck [4]
Quick change of tools with CENTROTEC shaft
Only clamp CENTROTEC tools in CENTRO-
TEC tool chucks.
8.2 Chuck BF-FX10 [5]
For clamping drill bits and bits with max. shaft di-
ameter of 10 mm.
Clamp tool centrally in the chuck.
8.3 Angle attachment XS-AS [6]
(accessories) Drilling and screwdriving at right an-
gle to power tool.
You can engage the angle attachment in 16 dif-
ferent angle settings.
8.4 Tool holder in the drill spindle [7]
Bits can be inserted directly into the hexagon sock-
et holder of the drill spindle.
9 Working with the power tool
9.1 On/Off switch [1-6]
Press = ON, release = OFF
LED yellow - lit continuously
Charger is ready to use.
LED green - flashing quickly
Battery pack is charged to maxi-
mum capacity.
LED green - flashing slowly
Battery pack is charged to 80%
and with reduced current.
LED green - lit continuously
Battery pack is charged.
LED red - flashing
General fault indicator, e.g.
incomplete contact, short circuit,
defective battery pack, etc.
LED red - lit continuously
Battery temperature is outside
permissible limit values (0 °C to
55 °C).
CAUTION
Risk of injury
Always switch off the power tool before adjusting
settings!
WARNING
Risk of injury
Always disconnect the battery pack before per-
forming any type of work on the machine!
CAUTION
Hot and sharp tools
Risk of injury
Do not use insert tools that are blunt or defec-
tive.
Wear protective gloves.
WARNING
Risk of injury
Always secure the workpiece in such a manner
that it cannot move while being machined.
