UG-KAPEX
9
GB
1 Symbols
Warning of general danger
Manual, read the instructions
Disconnect from the power supply!
CAUTION! Danger of crushing fingers!
The illustrations specified are located at the
beginning and end of the operating manual.
2 Scope of delivery
Base frame UG-KAPEX
Trimming attachment KA-UG
3 Technical data
4 Intended use
The base frame UG-KAPEX was designed
specifically for use with Festool compound
mitre saws KS 120 EB and KS 88 E.
The trimming attachment KA-UG was de-
signed specifically for fitting to the base
frame UG-KAPEX.
The base frame was designed for sawing
boards and profiles in combination with a
power tool.
5 Safety instructions
Warning! Read all safety warnings
and all instructions.
Failure to follow the
warnings and instructions may result in elec-
tric shock, fire and/or serious injury.
Save all warnings and instructions for
future reference.
–
Remove the plug from the socket be-
fore adjusting the machine settings or
changing accessory parts.
Some acci-
dents are caused by power tools starting
accidentally.
–
Set up the base frame correctly before
attaching the power tool.
Set up the
base frame correctly to prevent the frame
from collapsing.
–
Secure the power tool safely on the
base frame before using it.
If the power
tool slips on the base frame, you may lose
control of the machine.
–
Place the base frame on a solid, even
and horizontal surface.
If the base
frame can slip or wobble, guiding the pow-
er tool or workpiece evenly and accurately
will not be possible.
–
Do not overload the base frame and
never use it as a ladder or trestle.
Overloading or standing on the base frame
may shift the centre of gravity of the frame
upwards and cause it to tip over.
–
Before transporting and starting
work, make sure that all screws and
[1-1] 2 x retaining rails
[1-2] 1 x base frame with rollers
[1-3] 1 x folding/fixed stirrup, handle
4 x screws M6x60
4 x nuts M6
1 x Allen key
[1-4] Left trimming attachment KA-UG-L
[1-5] Right trimming attachment KA-UG-R
1 x Allen key
Base frame UG-KAPEX
Length of base frame without trimming attachment 400 mm
Length of base frame with trimming attachment on one side 1880 - 2800 mm
Length of base frame with trimming attachment on both sides 3360 - 5200 mm
Working height 900 mm
Max. load UG-KAPEX/KA-UG 100/20 kg
Weight of UG-KAPEX without compound mitre saw 10.1 kg
Weight of KA-UG 4.6 kg
WARNING
The user will be liable for damage due
to improper use.
