Fetco CBS-1132-XV+ - Specifications and Requirements; General Specifications

Go to fetco.com for the latest versions of all information Page 2 User Guide & Operator instructions P166 Re0 NOVEMBER 2017
Rou
g
h-In Drawin
g
s
CBS-1131 XV+ Front CBS-1132 XV+ Front CBS-1131 XV+&CBS-1132 XV+ Side
WIRING METHODS: REFERENCE ONLY: SEE THE WIRING DIAGRAMS AT BACK OF THIS GUIDE
CBS-1131 XV+ 120 volt models with cord and plug
SKU E113172; E113173
CBS 1132XV+ models 200-240 volt L1, L2,G
CBS-1131XV+ models for 200-240 volt
Electrical installation, service and field conversion is to be made only by licensed electrician.
Disconnect equipment from power suppl
y
before service
Specifications and Requirements
Water Requirements: Coffee Filter Size:
CBS-1130 XV+: 20-75 psi
g
,
(
138-517kPa
)
2
g
pm
(
7.60 lpm
)
13” X 5”
–
standard FETCO # F002
Water supplied to hot bevera
g
e equipment should be filtered Electrical: See electrical confi
g
uration chart.
Water inlet fittin
g
is a 3/8 inch male flare. Temperature, as set b
y
factor
y
:
Brew Volume: Full Batch Up to 1 gallon/3.8 liters per brew 200°F (93°C) inside water tank (at sea level)
Total Brew C
y
cle—Factor
y
settin
g
: 5.5 minutes=[4 minute brew time + 1.5 minute drip dela
y
]
Brew-Process parameters are user controllable for:
Brew Volume, Brew Time, Prewet Percent and Prewet Dela
y
, Drip Dela
y
G
W
G
W
NEMA PLUG CONFIGURATION
NEMA 5-15P NEMA 5-20P NEMA 6-15P
1
