PLANER SPECIFICATIONS
Model
Number
Cutting
Width
Cutting
Depth
Tilt Sideshift
Overall
Width
Overall
Height
Overall
Depth
Shipping
Weight
LAF5416
SSP16 HF
16” 0 – 6”
+
15q
24” 66” 33” 60” 1708 lbs
LAF5418
SSP18 HF
18” 0 – 6”
+
15q
24” 66” 33” 60” 1763 lbs
LAF5420
SSP20 HF
20” 0 – 6”
+
15q
24” 66” 33” 60” 1844 lbs
LAF5424
SSP24 HF
24” 0 – 6”
+
15q
24” 66” 33” 60”
1925 lbs
LAF5430
SSP30 HF
30” 0 – 6”
+
12.5q
24” 66” 33” 60” 2134 lbs
LAF5436
SSP36 HF
36” 0 – 6”
+
10q
24” 66” 33” 60” 2235 lbs
PLANER REQUIREMENTS
Model Number Required Pressure Required Flow
LAF5416 SSP16 HF 2200 psi 24 gpm
LAF5418 SSP18 HF 2200 psi 28 gpm
LAF5420 SSP20 HF 2200 psi 28 gpm
LAF5424 SSP24 HF 2200 psi 28 gpm
LAF5430 SSP30 HF 2200 psi 28 gpm
LAF5436 SSP36 HF 2200 psi 31 gpm
TORQUE SPECIFICATIONS FOR STANDARD MACHINE HARDWARE
(FOR REFERENCE ONLY)
Bolt Size SAE Grade Bolt Torque Ft./Lbs Bolt Size SAE Grade Bolt Torque Ft./Lbs
0.31 - 18 5 17 0.63 - 11 5 150
0.38 - 16 5 30 1.00 - 8 5 580
0.50 - 13 5 75 1.12 - 7 5 794
0.56 - 11 5 120
