POWER UNIT SPECIFICATIONS
IMPORTANT Exceeding any of the maximum recommended tractor or power unit specifications
CAN result in damage to this product and
WILL
void all FFC Attachments warranties.
DESCRIPTION SPECIFICATIONS
Weight of Power Unit without Planer 11000 lbs. maximum
Operating Capacity of Power Unit’s loader 3750 lbs. maximum
Lift Capacity of Power Unit’s loader 7500 lbs. maximum
Hydraulic Pressure Output 5,000 psi. maximum
Front or Rear Ballast As required to maintain full power unit stability.
(see the shipping weight on page 22, then see the
operator’s manual(s) for you power unit, loader, and quick-
attach for your ballasting needs.)
PLANER MOUNTING
SAFETY FIRST!! READ AND UNDERSTAND THE SAFETY INSTRUCTIONS (pages 2-4 of this
manual) BEFORE BEGINNING ANY PLANER MOUNTING
1. Place this product on a firm, level surface that is large enough to safely accommodate this product, your power unit
and all workers involved in the mounting process.
2. Refer to the operator’s manual(s) for your power unit, loader, and quick-attach and follow the mounting instructions
contained therein.
3. Carefully raise the loader and cycle the tilt cylinders to check clearances and to verify that all mounting procedures
have been successfully completed.
4. IMPORTANT: Lubricate all grease fittings before connecting this product to your power unit’s hydraulic system.
Refer to PLANER MAINTENANCE on page 10 and follow the instructions.
ELECTRIC HARNESS AND ACTUATOR INSTALLATION
MATERIALS NEEDED: Nylon cable ties.
1. Attach the control box to a location convenient for the operator to control the planer without hindering operation of the
power unit. Use the magnet on the back of the control box to secure the control box with the toggle switches on top.
CAUTION
Failure to obey the following procedures may result in personal injury.
x To avoid electric shock during the wiring harness installation, remove the ground cable
from the battery of your power unit.
2. Remove the ground cable from the negative (-) post of your power unit’s battery.
3. Remove the nut from the POSITIVE (+) cable clamp on the battery and slide the RED wire ring terminal from the 9’
wiring harness cable over the positive (+) cable clamp bolt. Secure the ring terminal with the nut.
4. Remove the nut from the NEGATIVE (-) cable clamp on the ground cable and slide the BLACK wire ring terminal
from the 6’ wiring harness cable over the negative (-) cable clamp bolt.
5. Reinstall the ground cable on the negative (-) post of the battery and secure the ring terminal and the ground cable
with the nut removed in the previous step.
6. Secure the 9’ wiring harness cable from the battery to the control box with your nylon cable ties.
7. Feed the 16’ wiring harness cable:
a) back to the left-rear area of your power unit,
b) past the loader arm’s rear hinge point by following the hydraulic hoses where possible, and
c) down the loader arm following the hydraulic lines.
8. Use your nylon cable ties to secure the 16’ cable’s female connector to the hydraulic lines next to the auxiliary
hydraulic quick couplers.
9. Straighten the 16’ cable and use your nylon cable ties to secure the cable to the hydraulic lines back to the loader arm
hinge point.
10. Allow sufficient slack in the cable at the hinge point to provide for a full range of motion of the loader arms. Use your
nylon cable ties to secure the cable to the loader frame below the hinge point and back to the control box.
11. Connect the male connector on the actuator cable to the female connector on the loader arm.
7
