WARNING
174) Battery fluid is poisonous and
corrosive: avoid contact with your skin and
eyes. The battery should be charged in a
well ventilated place, away from naked
flames or possible sources of sparks:
danger of explosion and fire.
175) Do not attempt to charge a frozen
battery: it must be thawed first, otherwise it
may explode. If freezing has occurred, the
battery should be checked by skilled
personnel to make sure that the internal
elements are not damaged and that the
body is not cracked, with the risk of leaking
poisonous and corrosive acid.
WINDSCREEN/REAR
WINDOW WIPER
176) 61)
REPLACING THE
WINDSCREEN WIPER
BLADES
❒ raise the wiper arm, press tab A fig.
124 of the attachment spring and
remove the blade from the arm;
❒ fit the new blade, inserting the tab
into the special slot in the arm, making
sure that it is locked;
❒ lower the wiper arm on the
windscreen.
REPLACING THE REAR
WINDOW WIPER BLADE
Proceed as follows:
❒ raise cover A fig. 125, undo nut B
and remove arm C;
❒ correctly position the new arm, fully
tighten the nut B then lower the cover
A.
SPRAY NOZZLES
Windscreen washer
The windscreen washer jets can be
adjusted rotating the side notch with a
screwdriver. If there is no jet of fluid,
firstly check that there is fluid in the
reservoir (see "Checking fluid levels" in
this chapter). Then check that the
nozzle holes are not clogged; use a
needle to unblock them if necessary.
124
F1D0100
125
F1D0101
138
SERVICING AND MAINTENANCE
