Fiat Panda 2015 - Page 149

Versions
0.9 TwinAir Turbo 90 HP
(*)
1.3 16V MultiJet 95 HP 1.3 16V Multijet 80 HP VAN
Type code 312A7000
312B1000 / 330A1000
(°) 312B2000 / 225A2000 (°°)
Cycle Otto Diesel Diesel
Number and position of cylinders 2 in line 4 in line 4 in line
Piston bore and stroke (mm) 80.5 x 86.0 69.6 x 82 69.6 x 82
Total displacement (cm³) 875 1248 1248
Compression ratio 10 16.8 16.8
Maximum power (EC) (kW)
66.2 / 57
(**)
70 59
Maximum power (EC) (HP)
90 / 77.5
(**)
95 80
corresponding engine speed (rpm) 5500 3750 3750
Maximum torque (EC) (Nm)
145 / 100
(**)
200 200
Maximum torque (EC) (kgm)
14.8 / 10.2
(**)
20.4 20.4
corresponding engine speed (rpm)
1900 / 2000
(**)
1500 1500
Spark plugs NGK ILKR9G8 - -
Fuel
Unleaded petrol 95 RON (EN
228 specification)
Diesel for motor vehicles (EN
590 Specification)
Diesel for motor vehicles (EN
590 Specification)
(*) For versions/markets, where provided
(°) Versioni Trekking, 4x4 and Cross
(°°) 4x4 versions
(**) With ECO button pressed
147
