7
FIAT PANDA ADVENTURE
❒
turn the jack handle to lower the car
and remove the jack;
❒
fully tighten the bolts, passing alterna-
tively from a bolt to the opposite one,
following the order shown in fig. 9.
When you have finished
❒
replace the partially open jack and
equipment used in the tool bag;
❒
re-organise the tool bag, complete
with tools, replacing it in its original
position.
WARNING The spare wheel must be
placed in the boot, under the carpet, as
shown in fig. 10.
WARNING Do not use inner tubes with
Tubeless tyres. Check pressure of tyres
and spare wheel on a regular basis.
fig. 10
F0G0615m
❒
ensure that the spare wheel (space-
saver spare wheel for versions/
markets, where provided) support
surfaces are clean and free of impu-
rities that could later cause the bolts
to loosen;
❒
mount the spare wheel (space-saver
spare wheel for versions/markets,
where provided), ensuring that the
pins N-fig. 8 are aligned with one of
the holes O on the wheel;
❒
screw the 4 fixing bolts;
fig. 8
F0G0204m
fig. 9
F0G0206m
