INSTALLING A UNIVERSAL ISOFIX CHILD
SEAT
Secure the seat using the special lower metal rings A
fig. 98 positioned between rear backrest and cushion,
then fix the upper belt (provided with the child
seat) to the attachments B fig. 98 located in the rear
part of the backrest, for versions with split rear
seat.
For versions with sliding split rear seat, use the
suitable catches shown in fig. 100 on the tube at the
base of the backrest.
"Universal Isofix” child seats can be fitted alongside
traditional child seats. Remember that when using
a Universal Isofix child seat, you can only use
approved child seats with the marking ECE R44
“Universal Isofix”.
fig. 98
F0W0177
fig. 99
F0W0087
fig. 100
F0W0427
