Fiat PANDA - Page 204

Replacing the wiper blades
Proceed as follows:
❒ raise the wiper arm, press tab A fig. 154 of the
attachment spring and remove the blade from
the arm;
❒ fit the new blade, inserting the tab into the special
slot in the arm, making sure that it is locked;
❒ lower the windscreen wiper arm on the
windscreen.
Do not operate the windscreen wiper with
the blades lifted from the windscreen.
Replacing the rear window wiper blade
Proceed as follows:
❒ raise cover A fig. 155, undo nut B and remove arm
C;
❒ correctly position the new arm, fully tighten nut B
then lower cover A.
fig. 152
F0W0186
fig. 153
F0W0222
200
