FIBARO Heat Controller User Manual

5
FIBARO The Heat Controller is a HomeKit-enabled
thermostatic head to control temperature in
your room using Bluetooth
®
low energy wireless
technology.
It measures the temperature and automatically
adjusts the heat level. It can be mounted without
tools on three types of thermostatic radiator valves.
You can create schedules via app to easily manage
temperature throughout the week.
ENGLISH
TIP: Check corresponding chapters of Quick Start
Guide for pictures.
Package contents (page 3):
• Thermostatic head,
• 2 adapters (for Danfoss RTD-N and RA-N valves),
• Maintenance key,
• Extra temperature sensor (optional),
• Manuals and warranty terms.
Download FIBARO app from the App Store (page 4).
First launch (page 5):
1) Connect the charger to the micro-USB port to
charge the device (Fig. 1).
2) Disconnect the charger when the LED ring pulses
green (device fully charged) (Fig. 2).
3) Dismount your current thermostatic head (Fig. 3).
4) Depending on type of your valve proceed normal-
ly or use adapter (Fig. 4).
5) Mount the device on the valve and tighten it by
turning the cap clockwise (Fig. 5).
6) Use the included key to click the button (Fig. 6).
7) Open the FIBARO app and tap icon (Fig. 7).
8) Application will guide you through the installa-
tion and pairing process.
Setup Code:
You will nd the Setup Code on the device's housing
and on the back of the Quick Start Guide.
Reset (page 7):
1) Use the included key to press and hold the but-
ton. When the LED ring glows yellow, release the
button (Fig. 8).
2) Click the button again immediately to conrm.
3) The device will be put in Standby Mode. Click the
button to activate it again.
Specications (thermostatic head):
Power supply: 3.7V Li-Poly battery pack
(non-replaceable)
Supported charger: micro-USB 5V, min. 0.5A
Radio protocol: Bluetooth
®
low energy
Radio frequency band: 2.4 GHz
Operating temperature: 0-40°C
Maximum water temperature: 90°C
Supported valves: M30 x 1.5, Danfoss RTD-N,
Danfoss RA-N
Dimensions (D x L): 56 x 74 mm
56 x 87 mm (with adapter)
EU directives compliance: RED 2014/53/EU
RoHS 2011/65/EU
Specications (sensor - optional):
Power supply: 3.0V CR2032 battery
(included)
Radio frequency band: 2.4 GHz
Operating temperature: 0-40°C
Dimensions (D x H): 38 x 12 mm
EU directives compliance: RED 2014/53/EU
RoHS 2011/65/EU
Warnings:
Failure to observe recommendations included in the
manual may cause risk to health or malfunction of the
device. The manufacturer, Fibar Group S.A. will not be
held responsible for any loss or damage resulting
from not following instructions of the manuals.
Using batteries other than specied may result in
explosion. Dispose of properly, observing environ-
mental protection rules.
This product is not a toy. Keep away from children and
animals! CR2032 coin cells are harmful if swallowed!
IMPORTANT: Read the full manual
before attempting to use the device!
For more information about the
device, like video guides, param-
eters, technical manuals, and
declarations visit our website:
manuals.baro.com/en/hk-heat-controller

FIBARO Heat Controller Specifications

General

Charger Port	microUSB
Charger Voltage (DC)	5V
Charging Current	500mA
Temperature Measurement Accuracy	±0.5°C
Wireless Technology	Z-Wave
Radio Protocol	Z-Wave Plus
Dimensions	56 x 74 mm
Operating Temperature	0°C to 40°C
Max. Water Temperature	90°C
Temperature Measurement Range	0°C to 40°C
Radio Frequency	868.4 or 869.8 MHz (EU), 908.4 or 916.0 MHz (US)
Range	up to 50m outdoors
Power Supply	Battery (non-removable)
