Power Connections: All S711D standalone modules
may be powered only by 12 -16 VDC. Connect input power
according to the label on the module.
Rack modules: Power connections are made automatical-
ly when the card is installed. To supply power to the rack,
connect the rack power supply to an AC outlet and set the
power switch to ON.
OPERATION
S711D links operate automatically once installed. To exe-
cute the test mode, see page 7. For an explanation of LED
color codes, see LED OPERATION and Table 20.
MAINTENANCE
There is no operator maintenance other than keeping the
units clean.
TECHNICAL SUPPORT
For installation assistance, or in the event that a unit should
fail or if the cause of a problem cannot be determined, con-
tact Fiber Options’ technical support at:
TOLL FREE: 800-342-3748
PHONE: 631-567-8320
S711D & S7711D Instruction Manual
