Fidelis Direct/Internal 10G - Page 5

QUICK START GUIDE
Fidelis Network™ Sensor Appliances
www.fidelissecurity.com ©Fidelis Cybersecurity
5
Direct/Internal Sensor Appliances With 10GbE Optical Ports
Cable Type
Admin
8P8C "RJ45" (copper) Cat 5/5e/6 patch cable
Prevent
8P8C "RJ45" (copper) Cat 5/5e/6 patch cable
Monitor-A
8P8C "RJ45" (copper) Cat 5/5e/6 patch cable
Monitor-B
8P8C "RJ45" (copper) Cat 5/5e/6 patch cable
Monitor-C
LC Connector Fiber SR Patch Cable, Multimode 850nM
Monitor-D
LC Connector Fiber SR Patch Cable, Multimode 850nM
ILO
8P8C "RJ45" (copper)
Cat 5/5e/6 patch cable
Figure 4: Rear Port Assignments — Direct/Internal 2500, 5000
Figure 5: Rear Port Assignments — Direct 10G & Internal 10G
