OPERATING INSTRUCTIONS
DEMOLITION HAMMER
3.
ADJUSTMENT AND OPERATION
EN 12 Adjustment and operation
2.
Tighting Bolt
3.
Adjustment Handle
4.
Oil Cover
5.
Switch
6.
Main Handle
DESCRIPTION AND LOCATION OF MACHINE PARTS
1.
Chuck
Assembly of bit
The tool must be switched off and unplugged when assembly a bit on
the tool.
Pull the grip reward.
Adjust the groove position while turning the bit, and furthermore insert it
until it hits the end of the hole.
Release the grip. Pull the tool to make sure that it is locked completely.
OPERATION
Working position of bit
If the grip is turned on the left, in the condition where the grip is pushed
rearward, the bit angle can be changed freely to any position
(according the type of bit)
Release grip and turn the bit, and make sure that it is locked completely.
Removing the tool
Switch off and unplug the tool. Let it cool before.
Push and hold the lock button rearward. Hold the bot and remove it.
Side handle
The side handle is already installed in the tool. You must fix it.
Screw the handle in place to fix it.
Use
Be careful of hidden electrical lines or gas and water pipes. Check the
working area, e.g. with a metal detector.
Check the product, power cord and plug as well as accessories for damage
before each use. Do you use the product if it is damaged or shows wear.
Double check that accessories or application tools are properly fixed.
