WET&DRY VACUUM CLEANER OPERATING INSTRUCTIONS
19
13
OPERATING INSTRUCTIONSASH VACUUM CLEANER
ENOperating instructions | Maintenance after use | Filter cleaning | Technical specifications
After turning the vacuum cleaner off
After vacuum cleaning is finished, turn off the appliance using the switch and pull the plug
from mains socket. Remove the hose from the sucking hole; hose removal requires applying
small force. Finally remove accumulated dust from the collecting container (Fig. 4).
8. MAINTENANCE AFTER USE
Unscrew the filter securing bolt and remove the filter.
Then clean or replace the filter.
When disassembling the filter proceed in steps according to Figures 5/A, 5/B, 5/C.
When assembling the filter proceed in steps according to Figures 5/D, 5/E, 5/F.
9. FILTER CLEANING
We recommend to clean filter at least once a month or when it is visibly fouled or vacuum
cleaning force is reduced and motor noise is higher than usual.
Never use vacuum cleaner without installed filter. Operating vacuum cleaner without installed
filter leads to motor damage.
Before filter cleaning always disconnect the vacuum cleaner from power supply.
Filter cannot be cleaned in a dish washer.
Do not use a hairdryer for filter drying.
The best cleaning method is to shake out the filter.
10. TECHNICAL SPECIFICATIONS
Voltage / Frequency .......................................................................................................... 220~230V, 50/60Hz
Input Power ....................................................................................................................................................... 1000W
Ash Vacuum-Cleaning ............................................................................................................................ up to 40°C
Filter ................................................................................................................................................................ HEPA filter
Metal Container ....................................................................................................................................................... 16L
Metal Hose ................................................................................................................................................................. 1m
Aluminium Hose ................................................................................................................................................ 0,35m
Castors ................................................................................................................................................................... 3 pcs
Weight ........................................................................................................................................................................ 4kg
Power Supply Cord ............................................................................................................................................ 4,3m
Noise Level ........................................................................................................................................................... 80 dB
User Manual – Language version only.
Vacuum cleaner assembly | Operating instructions | Filter cleaning
6. VACUUM CLEANER ASSEMBLY (see pic. 2)
Before assembly or disassembly of accessories individual parts always first disconnect the plug
from mains socket.
Prepare all accessory parts.
Put the tube on the hose handle.
Assemble the flexible hose according to the figure and insert its ending with a connector
into the suction hole on vacuum cleaner upper side. Push inwards and a click is heard at the
rightposition.
Install filter.
Connect wheels.
7. OPERATING INSTRUCTIONS
Turning on/off
The vacuum cleaner is turned on by the switch I / 0 on the body of the vacuum
cleaner - position I.
Position II switch activates the drawer, but the cleaner remains off only to turn on the
connected device.
After turning the vacuum cleaner off
After vacuum cleaning is finished, turn off the appliance using the switch and pull the plug from
mains socket. Remove the hose from the sucking hole; hose removal requires applying small
force. Finally remove accumulated dust from the collecting container.
Clean or replace the filter.
8. FILTER CLEANING
