CORDLESS DRILLS OPERATING INSTRUCTIONS
Machine description and included contents | Putting into operation
3. MACHINE DESCRIPTION
AND INCLUDED CONTENTS
Machine description (see pic. 1)
A) Keyless
chuck
B) Torque setting ring
C) Rotation direction switch for movement forward/back and neutral position safety switch
D) Trigger
switch
E) Handle
F) Battery charge level LED display
G) Battery
H) 2 speed switch
Machine description (see pic. 2)
1) Batter
y adapter
2) Battery
Supplied contents
Carefully take the machine out of the packaging and check whether all the following parts are present:
Cordless drill with battery
Battery charger station
User's manual
If there are pa
rts missing or they are damaged, please contact the vendor from whom you bought the machine.
4. PUTTING INTO OPERATION
Charging the machine
Proceed step by step according to the user's manual and use the pictures as a guide so that the assembly
process is as easy as possible.
1. Take the battery out of the machine, press the release button and pull down to remove the battery.
2. Place the charger on a table near a power socket.
3. Properly insert the battery into the charger.
Note: The battery may be inserted into the charger only in one way.
4. Connect the charger power cord to a power socket. At this time both the red and the green indicator light will
be on.
EN 12
I) Lighting of the working area
