Check for parts online at www.getfieldsedge.com or call 800-345-6007 M-F 8-5 21
Operator's Manual
String Mower M200
KEY PART # DESCRIPTION QT Y.
1 19927 BOLT M10 X 1.5 X 60 HEX 4
2 16903 NUTM10X1.5X13NYLOC 5
3 16889 SCREW 4.8 X 1.6 X 20 MM PHILIPS 2
4 19944 BUSHINGM12X23RUBBER 1
5 60005058 DECKFRAME 1
6 60005008 EXTENSION SPRING 1.5 INCH LONG 1
7 19968 “V”PULLEYANDBEARING 1
8 16318 SPACERJACKSHAFTSTRINGMOWER 1
9 19936 BOLT M10 X 1.5 X 20 HEX SHLDR 1
10 19932 IDERBRACKETASSEMBLY 1
11 19934 PULLEY3LANDBEARING 1
12 60005003 BELT 3L 45.5 (18.75) 1
KEY PART # DESCRIPTION QT Y.
13 16400 NUTM8X1.0NYLOC 4
14 19938 AXLEANDBRACKETASSEMBLY 2
15 19945 BOLT M8 X 1.25 X 20 HEX 4
16 18898 WASHERM14X22X3.8SPRINGLOCK 2
17 19904 WHEEL SPACER 14 X 22 X 43 MM 2
18 18773 KITWHEEL&BEARINGS 2
19 W1265V0913 NUTM6X1.0NYLOC 1
20 60005018 TRAILING SHIELD 13.28 V 1
21 19937 BOLT M6 X 1.0 X 285 CARRIAGE 1
22 19953 RIVET M5 X 10 PHILIPS HEX 2
23 60005021 SHIELDMOWERBLACK 1
24 16540 CUTTERLINESTRINGMOWER 1
25 19931 SCREW M5 X 3 X 15 PHILIPS 4
Base Unit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
