21
Check for parts online at www.geteldsedge.com or call 800-345-6007 M-F 8-5
Operator's Manual
String Mower M220
KEY PART # DESCRIPTION QT Y.
1 16903 NUT M10 X 1.5 X 13 NYLOC 5
2 16889 SCREW 4.8 X 1.6 X 20 MM PHILIPS 2
3
60005058
DECK FRAME 1
4 19944 BUSHING M12 X 23 RUBBER 1
5 17227 BOLT M10 X 1.5 X 25 SHLDR 12 X 63 2
6 18773 KIT WHEEL & BEARINGS 2
7
60005008
EXTENSION SPRING 1.5 INCH LONG 1
8 19932 IDLER BRACKET ASSEMBLY 1
9 19968 "V" PULLEY AND BEARING 1
10 19936 BOLT M10 X 1.5 X 20 HEX SHLDR 1
11 19934 PULLEY 3L AND BEARING 1
12
60005003
BELT 3L 45.5 (18.75) 1
13 16400 NUT M8 X 1.0 NYLOC 4
14 19945 BOLT M8 X 1.25 X 20 HEX 4
15 19931 SCREW M5 X 3 X 15 PHILIPS HEX 4
16
60005010
GUARD ASSEMBLY RUBBER BLACK 1
17
60005021
SHIELD MOWER BLACK 1
18 16540 CUTTER LINE STRING MOWER 1
19 19953 RIVET M5 X 10 PHILIPS HEX 2
20 19937 BOLT M6 X 1.0 X 285 CARRIAGE 1
21
60005018
TRAILING SHIELD 13.28 V 1
22 NUT M6 X 1.0 NYLOC 1
KEY PART # DESCRIPTION QT Y.
23 17221 WHEEL SWIVEL ASSEMBLY MOWER 1
24 14920 • NUT M12 X 1.75 NYLOC 1
25 18106 • BOLT M8 X 1.25 X 20 HEX 2
26 21940 • BUSHING SHLDR 8 ID X 7.4 MM 2
27 17223 • SWIVEL FRAME MOUNT 1
28 19212 • SWIVEL LATCH MOUNT 1
29 19213 • SWIVEL CABLE CLIP MOWER 1
30 19694 • SWIVEL AXLE BRACE MOWER 2
31 21939 • BOLT M8 X 1.25 X 15 CARRIAGE 4
32 17508 • WASHER 13 X 30 X 2 NYLON 2
33 17176 • WASHER 18 X 50 X 2 NYLON 1
34 17224 • SWIVEL PIN MOWER 1
35 17225 • SWIVEL SPRING MOWER 1
36 17222 • SWIVEL WHEEL MOUNT 1
37 3252 • NUT M8 X 1.25 HEX 6
38 3245 • WASHER M8 X 24 X 2.2 MM 2
39 17177 • BOLT M12 X 1.75 X 25 SHDLR 1
W1265V0913
