12.Battery charging port
(located below the main beam of the frame)
11.Hold and press with your fingers,folding the pedal
(Note:After the car is stationary, it does not run for 10 minutes to enter the sleep mode and automatically shut down.)
1.Brake power off system
2.Mobile phone bracket &USB Port
3.Headlight button
4.L:Normal model
5.M:Electric Motorcycle model
6.R:Power Assist model
7.Horn button
8.Instrument
9.Power lock
10.Speed handlebar
１
2
3
4 5 6
7
8
9
10
12
11
5
