1.Brake power off system
2.Light/horn button
3.Power switch
4.Power adjustment
5. Power off brake
6.Quick lock
7.Speed-up rotating handle
8.Assistance Gears light
9.Power light
10.Power on/off button(Long press on or off)
11.Assistance Gears
(Note:After the car is stationary, it does not run for 10 minutes to enter the sleep mode and automatically shut down)
12.Battery charging port
(located below the main beam of the frame)
low
mid
high
4
5
6
7
8
9
10
11
1
2
3
12
13 14
L R
15
R
L
Use a 15mm open spanner to clamp the pedal shaft core and tighten it in the direction of the arrow (left counterclockwise, right clockwise, as shown).
(Note:When installing the pedal, be aware of the left and right, align the installation horizontally to prevent the pedal or crank slip)
13.Pedal 14.Left 15.Right
5
