13.Battery charging port
(located below the main beam of the frame)
13
1.Brake power off system
2.Light/horn button
3.Horn
4.Power on/off button
5.Power adjustment
6.Speed regulation
7.Power off brake
8.Battery level
9.speed
10.Electric assist gear
11.Speed-up rotating handle
12.USB output port
(Note: The bike will automatically shut down when it is stationary if not used within 10 minutes.)
14 15
L R
16
R
UUse a 15mm spanner to clamp the pedal shaft core and tighten it in the direction of the arrow (left counterclockwise, right clockwise, as shown).
(Note: When installing the pedal, be aware of the left and right, align the installation horizontally to prevent the pedal or crank slip.)
14.Pedal 15.Left 16.Right
3
km/h
2
3
4
5
9
8
10
１
12
6
7
11
5
