II. Bike Diagrams
1
2
6
3
4
8
9
10
7
11
12
13
14
15
16
171
5
1.Seat tube
2.Quick lock
3.Brake disc
4.Motor
5.Chain
6.Shock absorber
7.Controller box
8.Folding system
9.Battery box
10.Charge port
11.Chain wheel
12.Pedal
13.Crank
14.Handle bar
15.Stem
16.Folding system
17.Headlight
