Step 1: Verify the control panel “Armed/Disabled” switch is in the “Disabled” position and sufficient time (15
minutes) has been allowed for capacitors in the system to dissipate their charge before proceeding.
Step 2: Verify that the power is off at the control panel and all electrical charges have been dissipated.
Step 3: Refer to the EPC Manual (doc. n° E06-051-X) for the remainder of this procedure. Also refer to Fike document
X.2.26.01-x Valve Actuator Assembly.
Step 1: Place the control panel “Armed/Disabled” switch in the “Disabled” position and allow sufficient time (15
minutes) for capacitors in the system to dissipate their charge before proceeding.
Step 2: Open the cover of the electrical connection junction box, remove the Valve Actuator Assembly lead wires
from the screw terminals and immediately shunt the lead wires by twisting them together securely.
Step 3: Use care not to pinch or penetrate the insulation on the Valve Actuator Assembly lead wires, disconnect and
remove the conduit on the Valve Actuator Assembly mounting boss.
Step 4: Remove the Valve Actuator Assembly leads from the conduit and remove the Valve Actuator Assembly from
the Valve Actuator Assembly housing. If the Valve Actuator Assembly has not been activated, handle with
care and follow all Valve Actuator Assembly Safety Procedures per Section 4.
