FILTRINOV FB - Technical Description of the Filtration Unit

18
TECHNICAL DESCRIPTION OF THE FILTRATION UNIT
2
3
6
2
5
7
1
4
Filter access lid.
Multi-directional, high-flow nozzle.
LED light (optional)
Dual filter cartridge housing incl. 2 leaf baskets.
Two suction skimmers.
In-ground section containing:
• Pumps
• Control panel (if light fitted)
Removable, lockable lid.
3
4
3
2
2
1
1
Filter pump
Control panel (optional)
Pool light transformer (optional)
Remote control unit
3
2
1
2 Leaf baskets
2 Filter cartridges
2 Skimmers
IN-GROUND SECTION
SUBMERGED SECTION
