LED LIGHT
5
VYour filtration unit may include
a white LED light as standard.
A MULTICOLOUR LED light op-
tion is also available in 11 non-ani-
mated colours incl. white and
with 5 sequence programmes
(remote control included)
(Manufacturer’s guide included)
Standard
Optional
SETTING THE TIMER
6
Date
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
Objet Visa
Vérifié par
Ce document est la propriété de la société SOLU-WATT, il vous est remis à titre confidentiel
Référence
FILTR.FB.LED
Notice client
4
Folios :
EPLAN Software &
Service
19/10/2022
et ne dois pas être reproduit ni communiqué à des tiers sans notre autorisation écrite.
19/10/2022
TN
A
Plan de base
Date de vérification
TN
Créateur
Indus.
Indice
Version
B
Q1
C 2A
3kA
KM1
7
8 1 2
3
L N
0
I
Auto
KATS11B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
V1
PGR07
Filtration pump
0.75kW 5A max
Lighting
transformer
Earth connection
Front-mounted filtration
and lighting controls
LN
PE
PE
N L
N L
WP2/M
2 P Flush-mounted
male connector
WP3/M
3 P Flush-mounted
male connector
WP3/HEM
3 P Flush-mounted
socket connector
Power supply 230V 50-60Hz
Use a 30mA + differential
protection system
A C16 thermal magnetic circuit
breaker
• Continuous mode ( 24-hour filtration)
Move the filter switch on the outside of the electrical panel to
«Manual».
• Auto mode (timed filter operation)
Move the filter switch on the outside of the electrical panel to
«Automatic».
Turn the clock hands to set the exact time relative to the pointer
(triangle) on the right of the clock.
Push the segments outwards to set the scheduled «On» times.
Sequencing principle:
Minimum 1 h of downtime after 4 h of operation.
> See the instructions attached to the panel
