FIMAK SPM-40 - Page 78

FİMAK
DD.009 / Rev. No 00 SPİRAL MİKSER MAKİNASI
Tarih 10.10.2012 Sayfa 78 / 92
4.2.1 HOW TO CHECK BELT TENSION?
4.3 PULLEY REMOVAL SCHEMA
The standard tension of belt should
be as the thickness of itself
(0, 5 cm).
Maintenance Instructions
