Fimar MCD/950CS - Control Descriptions

▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ BELL PACKAGING MACHINE MCD
GB
C334606202.fmIDM
- 16 - English language
CONTROL DESCRIPTIONS
The appliance is equipped with the listed control devices, required to run its main functions.
A) Main switch: used to turn electrical power on and off.
B) Button: it activates and deactivates the equipment operation.
C) Display: it shows warning/alarm messages and working parameters.
D) Button (SET): it sets up the operation parameters of equipment.
E) Button (+): to increase the value of the selected parameter or to scroll the programmes.
F) Button (-): to decrease the value of the selected parameter or to scroll the programmes.
G) Button (PUMP/GASTRO): it activates and deactivates the pre-heating of the vacuum
pump.
When the equipment is operating with closed holding bell ??, press the button once to
carry out quick sealing and to open bell.
H) Vacuum gauge: it detects the negative pressure generated by the equipment inside
bell.
L) Printer: it prints one or more receipts showing the date of expiry of the product and, by
means of the special keyboard, it shows the ingredients contained in the bags on the
product (for model MCD/S - MCD/CS only).
To replace the paper roll for receipts press button(L1) and pull both side flaps of
the housing outwards.
Description
Unit of
measure
MCD/520CS MCD/650CS MCD/750CS MCD/950CS
Power kW 0,83 1,31 1,5 2,2
Power supply V/Ph/Hz
230V/1N/50-
60Hz
400V/3N/50-60Hz
Length of sealing bar mm 520 650 750 950
Flow rate of vacuum
pump
m³/h 25 40 63 100
Maximum vacuum
percentage
98%
Useful dimensions of
vacuum chamber
mm 530x530x200 660x540x200 760x540x200 960x540x200
Appliance
dimensions
mm 630x690x1050 770x690x1050 870x690x1050 1050x690x1050
Packaging
dimensions
mm 830x830x1280 1050x850x1350 1050x850x1350 1250x850x1350
Net weight kg 93 150 175 200
Installation type Floor installation
Noise level dB (A) < 70
