FINAL SOUND 90i/150i Loudspeaker Manual vs. 1.4 -US- c FS 2007RJ 7
.
5. FINAL 90i/150i floor stand mounting instructions
A. Install the black ‘wall’ plate to the bracket, using the 4 enclosed hexagon bolts
B. Insert the ball-bar into the cover plate and screw the cover plate onto the wall plate with the 2 hexagon bolts Do
NOT tighten before the panels are mounted and adjusted
C. Install the bracket to the metal tube, and firmly attach the 3 countersunk bolts
D. Install the footplate to the metal tube’s other side and again firmly attach the 3 button head screws
E. Glue 3 rubber pads to the footplate for your convenience
6. Parts overview
Floor Stand Package
Stereo Electrostatic Panel Package
2 metal tubes 4 M5x16 hexagon screws 1 ball-bar/ 1 allen key
2 footplates 3 M3x16 countersunk
head screws
1 black wall plate
1 black cover plate
2 brackets 3 M3x16 button head screws
2 M5x16 hex screws
2 allen keys Rubber pads Plugs/screws for wall mounting
