84 Finometer® Model-2 User’s Guide
9.3.3 Analog output connection
Item Specification
Analog output
range
4.0 0 to V
Resolution mV uts) 2.5 (all outp
Zero-offset
± 5 m V
Internal impedance
< 1Ω (all outputs)
Output current
capability
2 mA (Short circuit proof)
15-pin HD-
connector
Corresponding signal
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
Pin 12
Pin 13
Pin 14
NC (Not Connected)
NC (Not Connected)
NC (Not Connected)
External input (Red)
NC (Not Connected)
Output 1 (Black)
Output 2 (Gray)
A-GND
A-GND
A-GND
A-GND
A-GND
Output 3 (Blue)
Shield
Pin 11
A-GND
Pin 15
Shield
Output 4 (Green)
