Swing Mode
Press the Swing button (17) to enable the Air Louvres (7) to move from side to
side to spread the air flow horizontally over a larger area of the room. Use the two
Vertical Airflow Adjusters (4) to adjust airflow vertically up and down.
Cooling Mode
1. Rotate the retaining catch upwards and pull out the Water Tank (8) from the
rear of the cooler and fill with it water. Do not fill the tank beyond the ‘MAX’
mark using the Water Gauge (10) on the front of the unit.
2. Check the water level during use and ensure that it does not fall below the ‘MIN’
mark on the Water Gauge (10) and top up if necessary.
3. To enhance the cool function, fill the Ice Bottles (11) and freeze them in the
freezer. Once frozen, place one ice bottle in the Water Tank (8) to cool the
water further. Two ice bottles are supplied so that one can be in the water tank
cooling the water whilst the other is being frozen and then swapped over when
the one in the tank has defrosted.
4. Press the Cooler button (12) and press either the Low (14), Med (15) or the High
(16) Fan Speed buttons for cool air output.
5. Press the OFF button (13) to switch off the fan.
DO NOT operate in the cooler mode without water in the Water Tank (8)
otherwise permanent damage may occur to the unit.
6. Empty the Water Tank (8) after use and during storage by placing the cooler
onto a sink drainer, carefully remove the Water Tank from the cooler and pour
out any remaining water into the sink.
